Xiaomi TV 86" MAX
Display
Display Type4K UHD
Resolution3,840 x 2,160
Color gamutDCI-P3 90% (typ)
Color depth1.07 billion (8-Bit + FRC)
Refresh rate120Hz
MEMC4K 120Hz
Viewing angle178°(H)/178°(V)
HDR
Dolby Vision IQYes
HDR10+Yes
HLGYes
Speaker
Speaker (Sound Output)
15 W + 15 W
Supports Dolby Atmos | DTS®:X
System
Android TV™ 11
Platform
Processor
MediaTek MT9617
CPU
Quad A73
GPU
Mali G52MC1
Smart home
Far-field Google Assistant
* Google Assistant is not available in certain languages and countries. Please refer to Google Assistant official website for more info.
Smart home control hub
Chromecast built-in
Supports Miracast
Design
Size
86"
Limitless display with no-bezel
Color
Grey
Stand
Double
Power button
Dimensions
Dimensions including base (L x W x H)
1924.04 x 441.42 x 1181.94mm
Dimensions not including base (L x W x H)
1924.04 x 91.32 x 1102.16mm
Packing size (L x W x H)
2080 x 220 x 1280mm
Weight
Weight including base
44.5kg
Weight not including base:
43.6kg
Packing weight
56.3kg
Wall mount
600*400mm
Material
Frame
Metal
Stand
Metal
Connectivity
Bluetooth
Bluetooth 5.0
Wi-Fi
Wi-Fi 6， 2.4GHz/5GHz
HDMI
2.0, 2.1, CEC
USB
2.0 x 2
Composite In (AV)
Yes
CI Slot
Yes*
Ethernet (Lan)
Yes
Optical Digital Audio Out
Yes
3.5mm headphone jack
Yes
Broadcasting system
DVB-T2/C, DVB-S2*
* CI Slot may vary depending on regions
* DVB-T2/C, DVB-S2 may vary depending on regions
Power
Power
450W
Voltage
100-240V ~ 50/60Hz
Operating environment
Temperature 0℃～45℃，Humidity 20%～80%
Storage temperature -15℃～45℃，Relative humidity<80%
Accessory
360° bluetooth remote control x 1
Screws bag x 1
Stands x 2
Power cable x 1
User manual x 1
Warranty card x 1
|
|
